Industrial Floor Scales, Standard Size Design

LC6

Designed to Meet NIST HB44 Class III
Wash Down Approved
Standard Sizes for Easy Replacement

Beschreibung

Standard scale construction makes replacing existing scales a breeze. The fully electronic design employs hermetically sealed, water-proofed load cells for precision in hostile environment. Adjustable stainless steel feet feature 3-ball suspension for quick, easy leveling.

SPECIFICATIONS
Excitation: 10 Vdc Output: 3 ±0.1 mV/V (calibration with known weights is required)
Accuracy: 0.03%FS (Designed to meet NIST H44 class III 3000d scale code)
Operating Temp.: -18 to 65°C (0 to 150°F)
Compensated Temp.: -10 to 40°C (15 to 105°F)
Thermal Effects:
Zero ±0.0013% FS/°F (0.0023% FS/°C)
Span ±0.0008% Rdg/°F (0.0014% Rdg/°C)
Maximum Load: 200% FS
Construction: Mild Steel, four 350 Ohm load cells and J box
Height:
3.38-3.62" (86-92 mm) for <10,000 Ib
3.75-4.13" (95-105 mm) for 10,000 lb
4.25-4.63" (108-118 mm) for 20,000 lb
Electrical: 15 ft, 4-cond. foil shielded, 20 gage PVC cable

Bestellangaben (Bitte Modellnummer angeben)

Artikelnummer/Beschr.

Stk

Beschreibung

LC6-4X4-2K

Consult Sales

Lieferzeit:

0-2,000 lb floor scale with 4' X 4' platform

LC6-4X4-5K

Consult Sales

Lieferzeit:

0-5,000 lb floor scale with 4' X 4' platform

LC6-4X4-10K

Consult Sales

Lieferzeit:

0-10,000 lb floor scale with 4' X 4' platform

LC6-6X6-10K

Consult Sales

Lieferzeit:

0-10,000 lb floor scale with 6' X 6' platform

LC6-6X6-20K

Consult Sales

Lieferzeit:

0-20,000 lb floor scale with 6' X 6' platform

LC6-4-RAMP

Consult Sales

Lieferzeit:

One 4' wide ramp (wt. 130 lb)

LC6-6-10K-RAMP

Consult Sales

Lieferzeit:

One 6' wide ramp, 10,000 lb capacity (wt. 185 lb)

*Alle Preisangaben in Euro.
Anmerkung: 1) Ramps are sold individually, not in sets.
2) All LC6 Series paltform scales require calibration with known weights by the end user.
